Red Fire Fighting Pump Set Diesel engine Fire Fighting Water Pump 500 gpm 130 psi

Wuhan Spico Machinery & Electronics Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap Red Fire Fighting Pump Set Diesel engine Fire Fighting Water Pump 500 gpm 130 psi from wholesalers

    Buy cheap Red Fire Fighting Pump Set Diesel engine Fire Fighting Water Pump 500 gpm 130 psi from wholesalers
    • Buy cheap Red Fire Fighting Pump Set Diesel engine Fire Fighting Water Pump 500 gpm 130 psi from wholesalers

    Red Fire Fighting Pump Set Diesel engine Fire Fighting Water Pump 500 gpm 130 psi

    Ask Lasest Price
    Brand Name : CNP NM FIRE
    Model Number : SCF125-100-300(UL)
    Certification : UL
    Price : USD5000-60000/set
    Payment Terms : L/C, T/T
    Delivery Time : 60 Days
    • Product Details
    • Company Profile

    Red Fire Fighting Pump Set Diesel engine Fire Fighting Water Pump 500 gpm 130 psi

    • NM Fire Split Case Diesel Engine Pump Set 500usgpm@130psi UL/FM Tornatech Controller
    • Product Details

    Diesel Engine
    Pump Set
    ( Heat Exchanger)
    Pump: NM Fire Split Case
    Model:SCF125-100-300(UL)
    Q=500usgpm H=130psi n=2950rpm

    Material:
    Casing---Ductile Cast iron
    Impeller---SS304
    Shaft--- AISI 4340
    Shaft sleeve---SS304
    Seal------ Gland packing
    Wear ring----Bronze
    Bearing---SKF
    Engine: NM&UL
    Model: NM4-105
    86HP at 2950rpm
    Controller : Tornatech (UL)
    Model: GPD-24-120/220

    Red Fire Fighting Pump Set Diesel engine Fire Fighting Water Pump 500 gpm 130 psi


    • Application:

    All petroleum, petrochemical ,chemical, military and naval institutes, oil fields of Petro China, Sinopec, CNOOC, pipelines Bureaus, oil repositories, oil terminals, construction companies, oil refineries, offshore platforms, etc.

    Fire-fighting Engineering Companies,airports,highway tunnels,hotels,hospitals,supermarkets,office buildings, national grain storages, thermal power plants, shipyards,paper mills, subway stations,railway stations, etc.

    Steel plants, residential regions,industrial and mining enterprises,house building materials supermarkets,etc.

    • CERTIFICATE


    • ABOUT NM FIRE​:

    • Product Range


    In addition to the above models, there are many model UL/FM testing in process.

    Looking forward to your enquiry.

    • FAQ

    Q1.Do you have the UL-LISTED Fire Pump Sets?


    Yes, We have the UL/FM and NFPA standard Fire Pump Sets.


    Q2.Please quote the XXGPM@XXXPSI Pump without driver.


    Sorry, pump are not sold separately, pumps and drives are sold together.


    Q3.I need your motor drive End-suction/Split-casing fire pump, what information shold I sent to you ?


    Sir/Madam,you can privide the Capacity, Heed, Voltage and Frequncy,we will make the quotation for you,If you need Jockey Pump or other accessories, please tell us together.


    Q4.If I need your Diesel Engine Drive End-suction/Split-casing fire pump, what information shold I sent to you ?


    You can sent the Capacity Heed, Temperature and Altitude (temperature and altitude will affect the performance of diesel engines).If you need Jockey Pump or other accessories, please tell us Voltage and Frequncy or accessories together.


    Q5.May I ask what is the lead time of this fire pump and the jockey piump if ever we order them from you?


    Under normal cicumstance,75days ,we will notify the delivery date after receiving the deposit.


    Q6.Please advise if you can also send me the cost for the freight?


    Pls. confirm the model first,then we wil estimate estimate. The Fire Pump Sets are customized production, actual packaging size and estimated size will be different.


    • Service:

    1. Reply within 24 hours.
    2. High-quality products and the most reasonable price
    3. Data and chemical technology support.
