    Red Professional Fire Pump Diesel Engine 144KW With Water Cold Cooling

    Ask Lasest Price
    Brand Name : CNP NM FIRE
    Model Number : IF05BTIH-F
    Certification : UL/FM
    Payment Terms : L/C, T/T
    Delivery Time : 35-40 Working Days
    Price : Negotiation
    • Product Details
    • Company Profile

    Red Professional Fire Pump Diesel Engine 144KW With Water Cold Cooling

    De Maas 144KW Fire Pump Diesel Engine For All kinds of Fire Pumps By UL/FM Aprroved


    Since 1922, De Maas is known as reliable manufacturer and supplier of high quality engines to the industry.
    Combining renowned base-products such as Doosan, lveco, JCB and Lister-Petter engines with the newest techniques, qualified employees and personal attention. This in combination with the highest manufacturing standards, the Dutch company De Maas offers reliable, customized fire pump engines all over the world for many years.


    De Maas Firefighting Engines:

    • Can answer worldwide and country specific demands for various specifications, including FM approval
    • Are thoroughly tested and certified in our own testing facilities in The Netherlands
    • Are manufactured with great accuracy and precision
    • Are available in a power range of 49kw-652kw (FM Approved) and 53kw-724kw (non-approved)
    • Have a proven record worldwide.

    General Engine DataIF05BTIH-F
    Type4 cycle, 4 Cylinder In Line, Water cooled
    Aspiration

    Turbo charged, Intercooled

    Cylinder TypeReplaceable
    Bore x Stroke(mm)104 x 132
    Displacement(litre)4.483
    Compression Ratio17.5 : 1
    Valves per Cylinder- Intake1
    - Exhaust1
    Valve Timing- IntakeOpening: 15⁰ BTDC - Close: 35⁰ ABDC
    - ExhaustOpening: 69⁰ BBDC - Close: ATDC
    Valves lashes at cold- Intakemm

    0.25 ±0.5

    - Exhaustmm

    0.5 ±0.5

    Combustion Type

    Direct Injection

    Firing Order1 – 3 – 4 – 2
    RotationCounter Clockwise, viewed from flywheel
    Dimension L x W x H (L=Construction Length)± mm

    977 x 955 x 1,537


    Engine Rating1,7602,1002,2002,3502,6002,8002,940
    IF05BTIH-FkW144144144

    Fuel System
    Injection PumpStanaDyne Rotary Pump type
    GovernorFixed speed control
    Fuel Lift PumpExclusive (Electric version as an Option)
    Fuel FilterFull flow, cartridge type
    Used FuelDiesel fuel according EN 590
    Fuel consumption at Full Load Approx.at 2,940 rpm266228220247
    Fuel consumption information at other Revs.See table no.03.400.06FCEN03
    Standard Supply line Sizemm10
    Standard Return line Sizemm10

    Electrical System24 Volts (Nominal)
    Starter motorkW3
    Battery Min. capacity recommendedAh180 (12 Volts)
    Quantity per battery bank2
    Battery Cold Cranking Amperes@ -18⁰C950
    Charging Alternator OutputAmp.90
    Engine stop device build in fuel pumpEnergized to Stop

    Advantage:


    First-Class international technical standards


    NM Fire is the only enterprise in China that obtained not only UL and FM certificates, but CCCF as well,also the first company in the world who was authorized by UL CCIC as witness testing center for both fire pumps and fire fighting engines.


    NM fire obtained fire diesel engine UL1247 and fire pump UL448 witnessed laboratory accreditation,fully proved that the company in terms of hardware and software strength,are to meet the

    strict requirements of UL certification.


    Service:


    Pre-service
    Introduce the product to the customer in detail,answer the question raised by customer carefully;
    Sale service
    1.Ensure product with high quality and pre-commissioning before delivery;
    2.Delivery on time

    After-sale service
    Provide considerate services to minimize clients’ worries.
