    High Power 130 KW Fire Pump Diesel Engine Suitable for All Fire Pumps

    Ask Lasest Price
    Brand Name : CNP NM FIRE
    Model Number : IF05ATIH-F
    Certification : UL/FM
    Payment Terms : L/C, T/T
    Delivery Time : 35-40 Working Days
    Price : Negotiation
    • Product Details
    • Company Profile

    High Power 130 KW Fire Pump Diesel Engine Suitable for All Fire Pumps

    High Power 130 KW Fire Pump Diesel Engine Suitable for All Fire Pumps


    Manufacturing with a personal touch


    We translate (almost ) all your wishes into a high quality firefighting engine. Not only technical requirements and demands, also wishes involving branding can be realized. Our personal touch goes beyond manufacturing, at De Maas we speak your language. We know our customers by name and our customers know us. We take time to get to know your business, needs and requirements. All of which result in a satisfying cooperation and the best customized engines.


    One of De Maas's specialities is the development and manufacturing of dedicated engines for sprinkler systems.The in house capabilities give us the possibility to develop a carefully selected base engine into a high quality,high performance firefighting engine.Experience over years have given us the knowledge to do that in line with the highest demanding standards required by the market.


    De Maas is continuously investing in the quality of their products and therefore in their staff and facilities. As a result, a modern engine test facility has been established in 2013 at the new premises in Zwijndrecht, The Netherlands. Engines can be tested according the required standards such as FM by qualified employees. Being a FM approved supplier, we highly value every step in the production process of our firefighting engines and can therefore guarantee reliable and safe engines, both listed and non-listed.


    General Engine DataIF05ATIH-F
    Type4 cycle, 4 Cylinder In Line, Water cooled
    Aspiration

    Turbo charged, Intercooled

    Cylinder TypeReplaceable
    Bore x Stroke(mm)104 x 132
    Displacement(litre)4.483
    Compression Ratio17.5 : 1
    Valves per Cylinder- Intake1
    - Exhaust1
    Valve Timing- IntakeOpening: 15⁰ BTDC - Close: 35⁰ ABDC
    - ExhaustOpening: 69⁰ BBDC - Close: ATDC
    Valves lashes at cold- Intakemm

    0.25 ±0.5

    - Exhaustmm

    0.5 ±0.5

    Combustion Type

    Direct Injection

    Firing Order1 – 3 – 4 – 2
    RotationCounter Clockwise, viewed from flywheel
    Dimension L x W x H (L=Construction Length)± mm

    977 x 955 x 1,537


    Engine Rating1,7602,1002,2002,3502,6002,8002,940
    IF05ATIH-FkW91118122125130131132

    Fuel System
    Injection PumpStanaDyne Rotary Pump type
    GovernorFixed speed control
    Fuel Lift PumpExclusive (Electric version as an Option)
    Fuel FilterFull flow, cartridge type
    Used FuelDiesel fuel according EN 590
    Fuel consumption at Full Load Approx.at 2,940 rpm266228220247
    Fuel consumption information at other Revs.See table no.03.400.06FCEN03
    Standard Supply line Sizemm10
    Standard Return line Sizemm10

    Electrical System24 Volts (Nominal)
    Starter motorkW3
    Battery Min. capacity recommendedAh180 (12 Volts)
    Quantity per battery bank2
    Battery Cold Cranking Amperes@ -18⁰C950
    Charging Alternator OutputAmp.90
    Engine stop device build in fuel pumpEnergized to Stop

    Advantage:


    First-Class international technical standards


    NM Fire is the only enterprise in China that obtained not only UL and FM certificates, but CCCF as well,also the first company in the world who was authorized by UL CCIC as witness testing center for both fire pumps and fire fighting engines.


    NM fire obtained fire diesel engine UL1247 and fire pump UL448 witnessed laboratory accreditation,fully proved that the company in terms of hardware and software strength,are to meet the

    strict requirements of UL certification.


    Service:


    Pre-service
    Introduce the product to the customer in detail,answer the question raised by customer carefully;
    Sale service
    1. Ensure product with high quality and pre-commissioning before delivery;
    2. Delivery on time;
    After-sale service
    Provide considerate services to minimize clients’ worries.
